SC753A-080-02 Image 1


The SC753A-080-02 is a servo drive in the SC750 Servo Drives series by Pacific Scientific. It is a key automation product, designed specifically to work with servo motors. This device is responsible for accurately interpreting signals sent by the control system and adjusting the motor's speed, position, and torque accordingly. The design of this servo drive complies with the highest standards, protecting its components from heat, water, dust, and other potentially damaging environmental conditions. A salient feature of the SC753A-080-02 is its ability to work with signals from a single resolver sensor mounted on the servo motor. This results in servo motors with high torque to inertia ratios and compact sizes, a signature feature of Pacific Scientific's products. With a maximum power output of around 4500W and a maximum peak torque of approximately 100Nm, this servo drive is suitable for a variety of industrial applications including CNC machining, printing, and drilling. Despite its robust and compact design, the SC753A-080-02 weighs only about 7.5Kg, making it transportable and flexible for various installation requirements. Additionally, this servo drive can be used with a serial communication link for integration with the ServoBasic Software used in motor control. It also features integrated safeguards that provide protection against high voltage and current that could potentially damage the system.

SC753A-080-02 by Pacific Scientific is a Single Axis Servocontroller unit in the SC750 Series. The SC753A-080-02 features a Power Level of 7.5A cont./15A peak and the 12 bit RDC (+/-22 arcmin, 1024 ppr) Option. This Servo Drive also has a position controller (resolver) and is a Custom Unit.

Revision Part #:

Manufacturer Pacific Scientific
Product Type Servo Drive
Model SC753A-080-02
Use Control of Servo Motors
Weight 7.5Kg
Power Output Maximum 4500W
Peak Torque Maximum 100Nm
Communication Serial Communication Link for ServoBasic Software
Safety Features Protection against High Voltage and Current
