MDD112D-N-030-N2M-130PA1
Bosch Rexroth Indramat
MDD112D-N-030-N2M-130PA1
Bosch Rexroth Indramat
Description
The MDD112D-N-030-N2M-130PA1 is a digital AC servo motor in the MDD Series by Bosch Rexroth Indramat. This compact, space-saving model operates at a nominal velocity of 3,000 revolutions per minute and is designed to generate a torque of 38 Nm at a current of 60.6 A when stationary. Featuring a digital servo feedback system and encoder for real-time motor output feedback, this model can work optimally under specified environmental conditions like temperature and moisture, but performance may degrade at temperatures above 40-degree Celsius. With a weight of 59 kg, this model requires careful handling during transport and installation. It is capable of providing an impressive 130.2 Nm torque when under maximum load and uses 222.2 A of current. The motor's casing is engineered to offer an IP65 degree of protection, making it an ideal pick for potentially explosive environments. The MDD112D-N-030-N2M-130PA1 is available in 'D' size with several other sizes and windings available through Wake Industrial. This globally-shipped product is easily identifiable by its type code labeled on the attached nameplate.
MDD112D-N-030-N2M-130PA1 by Rexroth, Indramat, Bosch is a Digital AC Servo Motor in the MDD Series. The MDD112D-N-030-N2M-130PA1 features a Nominal Speed of 3000 min and a Centering Diameter of 130 mm. This Digital AC Servo Motor has a Motor Length of D and comes With 14.0 Nm Blocking Brake.
Revision Part #:
MDD-112D-N-030-N2M-130PA1MDD112D N 030 N2M 130PA1MDD112D-N-030-N2M-130-PA1MDD112D-N-O3O-N2M-13OPA1MDD112DN030N2M130PA1| Manufacturer | Bosch Rexroth Indramat |
|---|---|
| Product Type | Digital AC Servo Motor |
| Model | MDD112D-N-030-N2M-130PA1 |
| Motor Size | D Size |
| Nominal Velocity | 3,000 revolutions per minute |
| Standstill Torque | 38 Nm |
| Standstill Current | 60.6 A |
| Peak Load Torque | 130.2 Nm |
| Peak Load Current | 222.2 A |
| Weight | 59 kg |
