MDD112D-N-030-N2M-130GA2
Bosch Rexroth Indramat
MDD112D-N-030-N2M-130GA2
Bosch Rexroth Indramat
Description
The MDD112D-N-030-N2M-130GA2 is a digital AC servomotor in the MDD Series by Bosch Rexroth Indramat. This servomotor features a 40Nm blocking brake, plain output shaft, and standard electrical connections for interfacing with a drive controller. The unit comes with a fully sealed housing and offers high heat conduction from the inner stator to the exterior wall, making it highly efficient. The MDD112D-N-030-N2M-130GA2 is designed for applications where precision is paramount, such as industrial automation and robotic systems. This servomotor allows for installation at altitudes up to 5000m and safeguards against dust and foreign object penetration, ensuring its reliability in various environmental conditions. The motor is equipped with a blocking brake operating on the closed-circuit principle. The unit also features a maximum 7mm side-to-side motion amplitude for sinusoidal oscillations and supports the Design B14 type mounting style. With a 30,000-hour bearing life per ISO 281 specifications, this servomotor ensures longevity and consistent performance. The MDD112D-N-030-N2M-130GA2 servomotor includes a temperature sensor and also features built-in data storage for its parameters, providing real-time feedback and enhancing the overall system performance. This unit is capable of bearing substantial axial loads, with the load calculations guided by a specific formula. The servomotor's weight is 59kg excluding the blower and blocking brake. It offers a duty cycle time of up to 15 minutes and a blocking brake with enormous 144,060Nm holding torque. This motor is typically shipped via reputable freight carriers, ensuring safe and efficient delivery.
MDD112D-N-030-N2M-130GA2 by Rexroth, Indramat, Bosch is a Digital AC Servo Motor in the MDD Series. The MDD112D-N-030-N2M-130GA2 features a Nominal Speed of 3000 min and a Centering Diameter of 130 mm. This Digital AC Servo Motor has a Motor Length of D and comes With 40.0 Nm Blocking Brake.
Revision Part #:
MDD-112D-N-030-N2M-130GA2MDD112D N 030 N2M 130GA2MDD112D-N-030-N2M-130-GA2MDD112D-N-O3O-N2M-13OGA2MDD112DN030N2M130GA2| Manufacturer | Bosch Rexroth Indramat |
|---|---|
| Product Type | Digital AC Servomotor |
| Model | MDD112D-N-030-N2M-130GA2 |
| Output Shaft | Plain |
| Unit Weight | 59kg |
| Operating Lifespan | 30,000 hours |
| Max Altitude for Installation | 5000m above sea level |
| Balance Class | N according to DIN VDE 0530 |
| Main Purpose | High precision applications |
| Max Torque | Dependent on the drive used |
