MDD112C-N-015-N2M-180GB0

Bosch Rexroth Indramat

MDD112C-N-015-N2M-180GB0

Bosch Rexroth Indramat

MDD112C-N-015-N2M-180GB0 Image 1

Description

The MDD112C-N-015-N2M-180GB0 is an AC servo motor in the MDD Series by Bosch Rexroth Indramat. This motor stands out for its high overload capacities, owed to its efficient heat conduction facilitated through a minimalist design. It is built to deliver high dynamic output thanks to its favorable torque-inertia ratio. Operating within an ambient temperature range of 0 to +45 degree Celsius, it offers a thermal time constant of 100 minutes. The motor has the capacity to perform at a nominal speed of 1,500 revolutions per minute and generate 28 Nm of continuous torque at standstill, utilizing a current of 22.2 A. The maximum potential torque of the motor is 97 Nm, achieved with a peak current of 82.6 A. The MDD112C-N-015-N2M-180GB0 model does not include blocking brakes, and it features a 180 mm centering diameter. It has a naturally convective housing design that enables optimal cooling. Additionally, the motor is IP65 certified, allowing for outdoor installations and providing protection against dust and water. The protective housing is finished with a durable black prime coating. Installation is typically done at elevations not exceeding 1000 meters above sea level.

MDD112C-N-015-N2M-180GB0 by Rexroth, Indramat, Bosch is a Digital AC Servo Motor in the MDD Series. The MDD112C-N-015-N2M-180GB0 features a Nominal Speed of 1500 min and a Centering Diameter of 180 mm. This Digital AC Servo Motor has a Motor Length of C and comes Without Blocking Brake.

Revision Part #:

MDD-112C-N-015-N2M-180GB0MDD112C N 015 N2M 180GB0MDD112C-N-015-N2M-180-GB0MDD112C-N-015-N2M-180-GBOMDD112C-N-015-N2M-180GBOMDD112C-N-O15-N2M-18OGBOMDD112CN015N2M180GB0
Manufacturer Bosch Rexroth Indramat
Product Type AC Servo Motor
Model MDD112C-N-015-N2M-180GB0
Thermal Time Constant 100 minutes
Operating Temperature 0 to +45 degree Celsius
Nominal Speed 1500 revolutions per minute
Continuous Torque 28 Nm
Peak Current 82.6 A
Centering Diameter 180mm
Protection Class IP65
